#12AU7-TII,PSVANE TUBES,TII-Series.

TII-Series: Positioning in exceeding totally, not only exceed all the same types of productions that always been imitating on the market, but also to exceed itself.

2AU7-TII is double triode small size novel tube, it is used as inverter drive push-pull amplifier in amplifying circuit.

Heater

Uf-----------------6.3(parallel connection) 12.6(series connection) V

If-------------------0.30 0.15 A

Direct Interelectrode Capacitances

No.1 No.2

input----------------- 1.6 1.6 PF

output--------------- 0.4 0.32 PF

grid to plate----------1.5 1.5 PF

Static parameter

Ua--------------100 250 V

—Ug-------------0 8.5 V

Ia---------------11.8 10.5 mA

Gm--------------3.1 2.2 mA/V

u--------------- 20 17

ri(approx)---------6.5 7.7 KΩ

Ug(approx)--------—11.8 —10.5 V

(when Ia=10uA)

class A1.maximum.single triode.

Ua----------------300 V

Pa----------------2.75 W

Ik(max)-------------20 mA

Ug----------------—50 V

Uh-k(pk)--------±200 V

with cathode bias-------------1 MΩ

with fixed bias-------------- 0.25 MΩ
