Item

MS-8201

Optics

Shooting Area

300×250mm

Zoom

≥8×optical zoom, ≥10×digital zoom

Focus

Auto

Aperture

Auto

Video System

Image Apparatus

CMOS 1/3" Image Sensor

Total Pixels

3,200,000

Horizontal clarity

≥1000TV line

TV System

PAL/NTSC

White Balance

Auto / manual

Comparison

≥2 separate screen

Function

Color/BW, negative, mirror, text/graphic, Brightness control, freeze, preview/shooting, electric volume control, RGB×2 matrix function

Image Save

80-320 frames

Illumination

Side lamp

LED×2

Base light

LED backlight

Input

Audio Part

Microphone input×1

AV Part

Audio × 1

VGA part

RGB×1

Audio×2

RS-232

RS232(Computer controllable)×1

HDMI Part

HDMI Input × 1

Output

AV Part

Audio × 1

VGA Part

RGB×1 ×

HDMI Part

HDMI Output × 1

USB Output

USB Port×1

VGA line-to-line scan

1024×768; 1280×1024; 1280 × 720

Control Modes

Control Panel; Remote Controller; USB Software Control

Cubage (W×D×H)

Setup

400×172 ×380mm

Folded

276×172 × 37mm

Weight

1.4KG

Environment

Power

DC 12V 1.5A

Energy Consumption

≤15W (Energy conservation)
